Weight: 7400 lbs.

Ground Clearance: 7”

Ground Pressure: 4.27 psi.



Length: 8’–9”

Width: 5’–7”

Height: 6’–10”



Capacities:

Diesel: 15 gallons

Hydraulic Oil: 15 gallons



STANDARD FEATURES



• Manual safety shutdown switches on each side of the machine



• Front and rear lights


• Removable keyed main switch



• Loud warning beeper that activates whenever the remote control joystick is activated



• Alternate hitch height position if additional tongue height is required



• Extended lower hitch position clears tracks and enhances maneuverability



• Standard 18” grouser tracks for greater traction and flotation



• All engine filters and fluid fillers are conveniently located



• Sturdy transmitter design for rugged off-road use



• Simple on-the-go battery replacement



• Dual joystick operation of tracks, mast and winch

ENGINE



Deutz  (TD 2.9L, 75 HP)





TRANSMITION



Hydro-static, infinite speed range





WARRANTY



Remote Trax comes with a warranty that covers 2 years / 2,000 hours parts and labor on the engine; 6 months parts and labor on everything else.





RADIO



• Back-up control cable for non-radio operation.



• Range of operation: 1,500 ft.



• Operates from three D-cell batteries





WINCH



Warn Series 12, rated working load 12,000 lbs. Remote controlled.
